Can-Am Maverick X3 72" Boxed Trailing Arms Gen 2

Give your 72 inch Can-Am Maverick X3 the rear suspension strength, clearance, and confidence it needs for serious off-road abuse. The CT Race Worx Boxed Trailing Arms Gen 2 are built for riders who push hard through rocks, desert chop, ruts, ledges, and high speed terrain.

These Gen 2 boxed trailing arms add over 4 inches of ground clearance, with more than 2.5 inches of usable clearance under the shock mount at the front of the tire. CT Race Worx builds them from a mix of .115 inch and .1875 inch Grade 50 steel, with over 1/4 inch of material thickness on the underside to take hits without folding. They bolt on with factory shocks, include sealed brake line bungs, and use a removable rear back strap to make installation easier.

FEATURES

• Designed for 72 inch Can-Am Maverick X3 models
• Gen 2 boxed trailing arm design
• Adds over 4 inches of ground clearance
• Provides over 2.5 inches of usable clearance under the shock mount
• Built from .115 inch and .1875 inch Grade 50 steel
• Over 1/4 inch of material thickness on the bottom side of the arm
• Bolt-on installation with factory shocks
• No shock modification required
• Sealed brake line bungs help protect the inside of the arm
• Includes supplied 6mm brake line hardware
• Removable rear back strap helps simplify installation
• Smart Shox mounts available upon request
• Available in Can Am Red, Octane Blue, Semi Gloss Black, Sunburst Yellow, Bare, Silver, Manta Green, Orange, Tan, Magma Red, and Chalk Grey
• Backed by CT Race Worx lifetime warranty

NOTES

Build time is usually 3-4 weeks.

VEHICLE FITMENT

Can-Am Maverick X3 72" Models
